| Features:
1) Use heat pipe for the heat conduction and can get a high heat absorption efficiency and rapid heat transfer.
2) The pipeline is made of red copper and conducted by heat transfer medium liquid; The crust used aluminum alloy mould material of high strength with airflow design.
3) Good anti-frozen performance, it can still work under the environment of -30℃.
4) Match with intelligence controller and assistant electrical heater, the system can provide hot water to you anytime.
5) The insulating layer uses polyurethane bulk bubble and has a good effect of temperature preservation.
Specification: we can customize according to customers’ requirement)
-Inter tank: SUS 304-2B food grade stainless steel with thickness of 1.0mm-2.0mm
-out tank: stainless steel/galvanized steel/color steel
-capacity: 80-500L
-Evacuated tubes: Dia.58mm*1800mm/850mm with heat pipe/U pipe
-Insulation layer thickness: 50mme
-Bracket: galvanized steel with thickness of 1.5mm-1.8mm
-heat preservation: 72 hrs
-Hail resistance: 25mm
-working pressure: 0.6MPa |
